Waste OTR Tyre Block Cutter

In continous with OTR tyre side wall cutter and OTR strip cutter, this OTR rubber block cutting machine is used to cut OTR rubber strips into rubber chips which will be ready for further size reduction by topsrecycyling cracker mill or rasper to make rubber mulch or crumb rubber.
  • TPS-OTRBC4500

  • TopsRecycling


This waste tires block cutter is used to cut end-of-life off-the-road (OTR) tires into rubber chips. It can also cut high pressure oil hose into small chips directly.


When the waste off-the-road (OTR) tires is cut into rubber strips, it comes into this block cutter to be further cut into rubber chips.


Unlike the waste tyre dual shaft shredder, this machine can cut the tyre strip from any size of waste off-the-road (OTR) tires.


The waste off-the-road (OTR) tires rubber chips made by this machine can be fed to rasper or cracker mill directly to make further size reduction to wire free rubber mulch. As per the market demand, it can be fed to rubber granulator to make rubber granules further, which can be used for making rubber tiles, or artificial turf.


Owing to the high quality and high percentage of nature rubber in waste OTR tyres, the best application is for making reclaim rubber. Just feed the rubber chips to cracker mill plant, and make 20 mesh rubber powder, which can be used for making high quality reclaim rubber. This is the major application of the rubber powder from off-the-road (OTR) tires in China.

Technical Data of OTR Tyre Side Wall Cutter





Motor   Power

90 Kw


Working   efficiency

2~3 tires   per hour


Life of   cutting blade

20 ~40   Tires


Machine   gross weight

Around   8000 kg


Figure   dimension

3300mm   × 2200mm × 1800mm

Advantages of automatic waste tyre cutting machine

1. Economical investment

2. High efficient of cutting waste OTR tyres, it can cut 8 to tons OTR waste tyres per hour

3. Reliable performance

4. Maintenance friendly

5. Low running cost

Working Process
Waste Mining Machinery Tyre Recycling Machine

Cut the OTR Tyre crown into rubber strips by OTR Strip cutting Machine

Waste OTR Tyre Recycling Line

Cut the OTR tyre side into rubber strips by OTR side wall strip cutter

Waste OTR Tyre Recycling Machine from China

Feed the OTR Tyre strips into this block cutter to be cut into rubber chips


Q:What is the rated electrical power of this Waste OTR Tyre Block Cutter?

A: The rated power is 90 kW, but the actual power consumption is 50% to 60% of the rated power only.

Q: How many operator does it required?

A: One person only

Q:How to load the tyre onto the machine?

A: By crane or forklift

Q: What's the cutting efficiency? How many tyres can cut per hour?

A: It can cut 8 to 10 tons of rubber chips per hour.

Q: How many blades are there?

A: One stationary blade and two rotary blades.

Q: What's the lifespan of the blade?

A: It can cut 1000 to 1500 tons of rubber chips from waste OTR tyres.
